A2598 (Vision Information)
| General Information |
| Component ID: |
A2598 |
| Component Type: |
SOIC |
| Description: |
For Reference Only |
| Line Placement: |
Not Applicable |
|
|
| Body Information |
| Component Length (1/1000″): |
2745.0 |
| Component Width (1/1000″): |
355.0 |
| Body Length (1/1000″): |
2745.0 |
| Body Width (1/1000″): |
250.0 |
| Component Height (1/1000″): |
220.0 |
| Placement Pressure (grams): |
150 |
| Primary Nozzle: |
45899164 |
| Alternate Nozzle: |
45899164 |
| FJ Primary Nozzle: |
User Defined |
| FJ Alternate Nozzle: |
User Defined |
| Accuracy: |
Standard |
| Pre-Orient: |
Yes |
| FlexJet Tact Control: |
|
|
|
| Lead Information |
 |
|
|
| Vision Information |
| Lead Inspection: |
No |
| Lead Tolerance From Body (1/1000″): |
0.0 |
| Lead Tolerance Across Body (1/1000″): |
0.0 |
| Lead Spacing Tolerance (1/1000″): |
0.0 |
| Lead Len Positive Tolerance (1/1000″): |
0.0 |
| Lead Len Negative Tolerance (1/1000″): |
0.0 |
| Coplanarity Tolerance (1/1000″): |
0.0 |
| Colinearity Tolerance (1/1000″): |
0.0 |
| P2P/NCC8 Ligthing Type: |
Front-Lit |
| P2P/NCC8 Ligthing Level: |
3 |
| Flexjet OTHC Front-Lit: |
|
| Flexjet OTHC Side-Lit: |
|
| Flexjet OTHC On-Axis-Lit: |
|
| Inspection Type: |
High Speed |
| P2P/NCC8 Camera/Mag: |
No Preference |
| Flexjet OTHC Camera/Mag: |
|
|
|
| Feeder Information |
| Default Feeder: |
100MATRIX |
| Default Rotation in Feeder (degrees): |
0 |
| Reject Station: |
Belt Reject |
|
|
|
|
|
