96 SBGA (Vision Information)

General Information
Component ID: 96_SBGA
Component Type: BGA
Description: For Reference Only
Line Placement: Not Applicable
Body Information
Body Length (mm): 18.999
Body Width (mm): 18.999
Component Height (mm): 1.379
Placement Pressure (grams): 150
Primary Nozzle: 51305103
Alternate Nozzle: 51305103
FJ Primary Nozzle:
FJ Alternate Nozzle:
Accuracy: Standard
Pre-Orient: No
FlexJet Tact Control: Fast
Bump Information
Bump Process: A
Bump Diameter: 0.480
BGA Inspection
All Ball Count: No
Pitch Inspection: No
Missing Ball Threshold (%): 30
Pitch Tolerance (%): 30
Vision Information
P2P/NCC8 Ligthing Type: Front-Lit
P2P/NCC8 Ligthing Level: 4
Flexjet OTHC Front-Lit: 5
Flexjet OTHC Side-Lit: 0
Flexjet OTHC On-Axis-Lit: 5
Inspection Type:
P2P/NCC8 Camera/Mag: No Preference
Flexjet OTHC Camera/Mag: Do Not Use
Orient Information
Orientation Inspection: No
Orientation Bump X (mm): 0.000
Orientation Bump Y (mm): 0.000
Check For Bump: Present
Pick Information
Reference X (mm): 0.000
Reference Y (mm): 0.000
Feeder Information
Default Feeder: 100MATRIX
Default Rotation in Feeder (degress): 270
Reject Station: Belt Reject
Flux Information
Dot Size (ml): 0
Speed: 0
Dry Delay (seconds): 0
Settle Delay (seconds): 0
